CALL FOR PRICE! Retail is $6999.00
Our pricing is too low to advertise!

The Stonex S980A GNSS RTK receiver, with an integrated Hemisphere GNSS Phantom GNSS board, has 800 channels and tracks all the present constellations and satellite signals (GPS, GLONASS, BeiDou, Galileo, QZSS & IRNSS). All GNSS signals are included at no additional cost.

Through the 4G GSM modem, a fast internet connection is guaranteed and the Bluetooth and Wi-Fi modules allow for reliable data flow to the controller. These features combined with the integrated 2-5 watt radio make the S980A the perfect base station receiver.

The color touch display and the possibility of connecting an external antenna makes the S980A an extremely effective receiver for every type of job. The S980A is also equipped with an E-Bubble and the optional IMU technology: fast initialization, up to 60° inclination.

The S980A has a 1PPS port which can be used in applications that require precise synchronization time to ensure that multiple instruments work together or that use the same parameters for system integration based on precise time.

FEATURES

800 channels GNSS board capable of supporting multiple satellite constellations
Support PPP service with L-band correction
aRTK functionality
Integrated UHF radio 2/5 watt
4G LTE and Bluetooth / WLAN datalink support
Touch colour Display
Integrates E-Bubble sensor
New IMU System that allows tilted measurements (Optional)
Rugged magnesium housing
1PPS port
Connector for GNSS external antenna
Easy configuration from Web UI

TECHNICAL SPECIFICATIONS

Tracking
Board:	Hemisphere GNSS Phantom 40
Channels:	800
GPS:	L1C/A, L1C, L1P, L2C, L2P, L5
GLONASS:	L1C/A, L1P, L2C/A, L2P, L3
Galileo:	E1, E5a, E5b, ALTBOC, E6
BeiDou:	B1, B2, B3, ACEBOC
QZSS:	L1 C/A, L1C, L2C, L5, L6
L-Band:	Atlas
IRNSS:	L5
SBAS:	L1, L5
Update Rate:	10 Hz 20 Hz (optional) 50 Hz (optional)
Operating System:	Linux
Memory:	32 GB
Positioning
Static Survey:	2.5 mm + 0.1 ppm RMS (Horizontal) 3.5 mm + 0.4 ppm RMS (Vertical)
RTK (< 30 Km):	5 mm + 0.5 ppm RMS (Horizontal) 10 mm + 0.5 ppm RMS (Vertical)
Code Differential:	0.40 m RMS
SBAS Accuracy:	0.60 m
Internal UHF Radio
Model:	TRM 501
Type:	Tx – Rx
Frequency Range:	410 – 470 MHz
Channel Spacing:	12.5 KHz / 25 KHz
Transmission Power:	2-5 watts
Maximum Range:	> 5 km with 2 watts > 10 km with 5 watts
Physical
Size:	Φ151mm x 94.5mm
Weight:	1.50 Kg
Operating Temperature:	-40 °C to +65 °C
Storage Temperature:	-40 °C to +80 °C
Waterproof/Dustproof:	IP67
Shock Resistance:	Designed to endure a 2 m pole drop onto a concrete floor with no damage
Vibration:	Vibration Resistant
Power Supply
Battery:	Rechargeable 7.2 V – 13.600 mAh
Voltage:	9 to 28 V DC external power input with over-voltage protection (5 pins Lemo)
Working Time:	Up to 10 hours
Charge Time:	Typically 4 hours
